Mode Electronic Transformer (12 Volt, 50 to 315 VA)
• Dimmable with ALLtypes of domestic and hard-fired dimmer. • Self resetting, short circuit and overload protection. • Complies with EC EMC and Low Voltage Directives. • Complies with EMC Emission Standard EN 55015. • Complies with EMC Immunity Standard EN 61547. • Energy efficient, ensures cool operating temperature. • Terminal covers and cable clamps. • Suitable for 50W to 150W or 210W loads. • Flame retardant moulded enclosure, UL94-V0. • Lightweight and compact size, only 400 grams. • Low audible noise throughout the dimming range. • 12V and 24V versions available. • Mode products are guaranteed for two years.
ET-HP refers to the “High Power” 150VA and 210VA products. Similar in style to the PUMA Transformers, the unit is supplied with terminal input connections and brass pillars on the output connections for reliable installation. ET-XP refers to the “eXtra Power” 255VA and 315VA products and has the same operational features as the ET-HP range, but with higher power handling capacities. Both the ET-HP and ET-XP products operate loads from 50VA The High Power range of transformers from Mode Lighting were designed originally for use in 12V low voltage track lighting control. The use of electronic transformers for higher power applications has been driven by the need for lighter, more efficient and quieter operation than conventional wirewound transformers and the ET-HP and XP ranges meet this demand. With the development of multi-lamp fittings and 24V light sources, the number of applications has grown and the range now consists of two sizes of transformer, each available in two power ratings with 12V or 24V outputs.
