Mode TP-03-18-TE Tiger Dimmer Pack Trailing Edge Dimmable Power Unit - 18 Channels of 3 Amps with Inductive 3 Amps

Reference: TP-03-18-TE

Condition: New product

Mode TP-03-18-TE Tiger Dimmer Pack Trailing Edge Dimmable Power Unit - 18 Channels of 3 Amps with Inductive 3 Amps

Share on Facebook!
Send to a friend

Send to a friend

Mode TP-03-18-TE Tiger Dimmer Pack Trailing Edge Dimmable Power Unit - 18 Channels of 3 Amps with Inductive 3 Amps

Mode TP-03-18-TE Tiger Dimmer Pack Trailing Edge Dimmable Power Unit - 18 Channels of 3 Amps with Inductive 3 Amps

- 18 x 3A Dimmable Power Unit.
- Trailing Edge Dimming suitable for LEDs with Minimum Loads on circuits
- THREE PHASE or Single Phase Power Supply.
- DIN RAIL Mounted Wiring Terminals.
- MINIATURE Circuit Breaker Protection

Recipient :

Name of your friend ^* :

E-mail address of your friend ^* :

^* Required fields

or Cancel
Print

Full Description
Product Specification

Product Category Feature	Lighting Control Systems
Condition	new
Availability	available for order
Brand	Mode
Manufacturer	Mode
Number of Dimmer Pack Channels	18 Channels
Dimmer Type	Trailing Edge and 0-10V Optional
Current Per Channel	3 Amps Per Channel
Dimmer Control Type	Wired Control
RCBO - Individual Circuit Protection	No

Mode TP-03-18-TE Tiger Dimmer Pack Trailing Edge Dimmable Power Unit - 18 Channels of 3 Amps with Inductive 3 Amps

- 18 x 3A Dimmable Power Unit.
- Trailing Edge Dimming suitable for LEDs with Minimum Loads on circuits
- THREE PHASE or Single Phase Power Supply.
- DIN RAIL Mounted Wiring Terminals.
- MINIATURE Circuit Breaker Protection.
- LEADING Edge Dimming Control.
- SWITCHING and 1-10V Dimming.
- SCENE Setting Control.
- DMX512 and RS232 Digital Control
- COOL OPERATION Under Full Load.
- ALARM or Emergency Override.
- ANALOGUE Control Inputs.
- COMPLIES with EC EMC and Low Voltage
- Directives (CE).
- MODE products are guaranteed for two years.
