Bose DesignMax DM8C-SUB 150W 8Ohm or 100V Line Ceiling Mount Sub-woofer Speaker in White Each


New product

Bose DesignMax DM8C-SUB 150W 8Ohm or 100V Line Ceiling Mount Sub-woofer Speaker in White Each

Coverage Onmi >200Hz

Freq: 38-115Hz

Power cont. 150W

Sensitivity SPL: 89dB

Impedance 8Ω/ 100V

More details

£ 460.00

£ 552.00 inc VAT

£ 552.00   tax incl.

Click to configure product options.
Product Category Feature Sound
Price Unit Each
Condition new
Availability in stock
Audio Product Type Speakers
Brand Bose
Manufacturer Bose
Speaker Type Passive 100V or 70V Line Speaker
Speaker Mount Type Ceiling Mount Speakers
Speaker Continuous Power Handling Wattage (W) 150W
Colour White
Bose DesignMax DM8C-SUB 150W 8Ohm or 100V Line Ceiling Mount Sub-woofer Speaker in White Each

Premium sound to maximize any design.
DesignMax loudspeakers bring outstanding audio and aesthetics to any commercial space. With 12 models to choose from, it’s easy to create tailored solutions that deliver instantly impressive sound. QuickHold mounting mechanisms make installation efficient, reducing strain and hassle — and saving substantial time. And with both black and white versions available, DesignMax loudspeakers integrate seamlessly with any décor.

The 150-watt DesignMax DM8C-SUB subwoofer features an 8-inch woofer, which delivers a 38 Hz - 115 Hz frequency range. The DM8C-SUB is ceiling-mounted, installed easily via QuickHold mounting arms


Combine models to complete any design, big or small — 12 loudspeakers to mix and match, from 2-inch, low-profile models to 8-inch, high-SPL compression-driver loudspeakers and outdoor-rated options

Deliver instantly impressive sound with custom Bose drivers — no DSP or EQ required. For even better sound, use select Bose DSPs and amplifiers to enable Bose loudspeaker EQ and SmartBass processing, which expands performance and response at any listening level

Blend into any room design with elegant form factors, minimum-bezel grilles available in black or white, and removable logos

Reduce installation time with the patented QuickHold mounting system, which also reduces strain, hassle, and the chance of product damage

Install easily — all models include Euroblock connectors; ceiling-mounted models include plenum-rated backcans, tile-bridges, and front-access audio wiring that makes installation and troubleshooting easier


  • Performing arts venues
  • Places of worship
  • Conference centers
  • Retail stores
  • Restaurants and bars
  • Hospitality venues


Technical Summary

Frequency Response (+/-3 dB)
45 - 117 Hz

Nominal coverage (H x V)
Onmidirectional below 200 Hz

Power Handling, peak
600 W

Maximum SPL @ 1m
111 dB

Frequency Range (-10 dB)
38 - 115 Hz

Power Handling, long-term continuous
150 W

Sensitivity (SPL/1W @ 1 m)
89 dB

Nominal Impedance
8 Ω (transformer bypass)
